100l-2000l Small High Shear Emulsifier Mixer Tank Stainless Steel Liquid Mixing Tank With Agitator

1.0 Units
MOQ
100l-2000l Small High Shear Emulsifier Mixer Tank Stainless Steel Liquid Mixing Tank With Agitator
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
Mixer Type: Agitator
Barrel Volume (L): 1000
Material Processed: Chemicals, Food, Medicine
Max. Loading Volume (L): 1000 L
Range of Spindle Speed(r.p.m): 1 - 2800 r.p.m
Max. Loading Capacity: Made to order
Weight (KG): 150 KG
Material: SUS304, Stainless Steel 304 / SUS316L
Condition: New
Product Type: food
Application: Liquid, Food Processing
Additional Capabilities: mixing,Heating and cooling
Voltage: Made to order
Dimension(L*W*H): Made to order
Power (kW): 7.5 kW
Warranty: 1 Year
Key Selling Points: Competitive Price
Applicable Industries: Food & Beverage Factory, Restaurant, Food Shop, Food & Beverage Shops
Showroom Location: None
Marketing Type: Hot Product 2020
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Warranty of core components: 1 Year
Core Components: PLC
Product name: After-sales Service Provided
Capacity: Made to order
Application samples: Mixing and Blending
Structure: Vertical or made to order
Whole System: Scrapping Agitator
Heating method: electric steam gas
Application scope: Food Pharmacy
Non-standard custom: Made to order
After-sales Service Provided: Online support, Video technical support
After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location: None
인증: CE
기본 정보
인증: CE
결제 및 배송 조건
Packaging Details: Milk cooling tank price 's pcking:Standard wooden case or made to order.
Supply Ability: 1000 Unit/Units per Year
제품 설명

Milk cooling tank price 's Suitable Material
Milk cooling tank price mainly used for milk and sugar, beverage, food and other elements and a variety of drugs in storage to stir well, is to make the dairy, beverage, pharmaceutical manufacturers indispensable equipment. Especially in ice cream production line indispensable equipment



Milk cooling tank price 's Characteristic

1, Quick open manhole;

2, Various types of CIP cleaning device;

3, Fly insect breathable cover health level;

4, Adjustable triangle leg;

5, Removable feeding tube;



Milk cooling tank price 's Material
Milk cooling tank price from Hangzhou Huihe Machine Facture Co., Ltd usually uses SUS304 or SUS316L to make if the customer has no special requirements.

Milk cooling tank price 's Detailed Picture

Milk cooling tank price 's Technical Parameter

Capacity (L)

1000

Barrel Size

Inner Layer: DN1100*800

Jacketed Layer: DN1200*600

Cladding Layer: DN1300*800

Material

SUS304

Agitator

Scrapping Agitator

Work Pressure of the Inner Layer (Mpa)

-0.04

Work Pressure of the Jacketed Layer (Mpa)

0.09

Motor

5.5kw 25r/m

Mechanical Sealing

Structure

Vertical, three layers (inner layer, jacketed layer and insulation layer), oval end enclosure for upside and 90 degree conical end enclosure for bottom, with vertical scrapping agitator, with operation panel and ladder

Accessories

DN400 manhole cover with sight glass, thermograph, vacuum pressure gauge, ball valves, check valve, control box, operation panel

Note:

The above is the standard size, any other special requirements, you can tell us, we will design and produce according to your needs.

Why choosing our Milk cooling tank price


1. Huihe machine have sales department, engineering department, after sales department, we

will provide you one-stop services for you;

2. We are not competing for the price but the high quality and friendly service we competition

3. The salesman and engineer will listen to your requirements and the effect which you want to reach patiently, and tailored for you;

4. The after sales colleague will service for you from place an order to the actual production;

5. 9 years of industry experience, industry leader;

6. Factory, office site visit.

Milk cooling tank price 's Packing Before Delivery
Authentication certificate and strength show

Hangzhou Huihe Machine Facture committed to design and manufacture of all kinds of stainless steel container.We can design according to customers' requirements for various kinds of stainless steel vessel, jacketed kettle, autoclave, milk cooling tank,and fermentor,etc . The equipments conform to the sanitary standards, thus effectively guarantee the people's health.

Huihe Company not only has a professional oversea sales team , but also has department of networks, sales Support and technology research and development,etc .We can supply turn-key project for design and manufacture of a whole production line, for example milk production line, juice production line ,tea production line ,etc.

Our core value is “service for small and medium food enterprises, and benefit of the public”, the products has been send to all over the world for 9 years . We are deeply trusted by the users in the food and beverage industry. We are famous in the food machine field for jacketed kettle, sterilization equipment, reaction tank and fermentation tank ,etc.

Since founded in 2005 , we service customers with good pre-sales support and after-sale service . We purpose is "guaranteed quality, complete variety , competitive price , timely delivery" .We insist our vision “Honest, pragmatic and win-win ” to provide best quality and service.
