Product Description:
High-speed shear emulsifier is a highly efficient and fast-uniform multi-material mixed machinery, which is usually under the circumstances of each material is incompatible.Through the high frequency of the cycle, to eventually get a stable high-quality product.
Product structure:
High-speed shear emulsifier machine, is upright installation of the emulsifier equipment.the stator is designed as a claw coupling structure.The material from the upper or lower part is inhaled and the high-speed shear, the efficiency of the quality has been multiplied, in order to avoid dead-corner problem.The product is suitable for installation in various sizes of reaction kettle on containers carry out mix.
Attention:All welded part are food grade 304 or 316 Stainless steel.
The advantage of the product:
The noise is low, the efficiency is high, running smoothly without a blind spot, 100% through the working cavity.Large processing flow, suitable for industrial continuous productionto deal with wild range of viscosity liquid.
| Model | EPH200 |
| Capacity | 200L |
| Type | Vertical |
| Jacket | Warming jacket and cooling jacket avaliable |
| Heating method | Steam heating or electric heating |
| Cooling method | Cold water recycle + plate exchanger |
| Working pressure | -0.09Mpa or high pressure |
| Water pot & oil pot | As option |
| Material | SUS304 SUS316 |
| Thickness | 2-10MM depending on size |
| Function | Homogenizing, mixing, emulfying |
Choose your emulfier head type
| Model | Volume(L) | Motor Power(KW) | Diameter(MM) | Stirring Speed(R/Min) | Pressure Inside Kettle | Pressure Inside Jacket |
| EPH100 | 100 | 0.75 | 500 | 1400-2900 | 0.1-0.25Mpa | 0.25Mpa |
| EPH200 | 200 | 0.75 | 600 | |||
| EPH300 | 300 | 0.75 | 750 | |||
| EPH500 | 500 | 1.5 | 800 | |||
| EPH1000 | 1000 | 1.5 | 1000 | |||
| EPH1500 | 1500 | 1.5 | 1200 | |||
| EPH2000 | 2000 | 1.5 | 1200 | |||
| EPH2500 | 2500 | 2.2 | 1400 | |||
| EPH3000 | 3000 | 2.2 | 1400 | |||
| EPH4000 | 4000 | 3 | 1500 | |||
| EPH5000 | 5000 | 4 | 1600 |
